51.2V Wall-Mounted Lithium Battery-Jiangsu Sloer Group Co., ltd

51.2V Wall-Mounted Lithium Battery Id：SW-51100 Place of origin：Shenzhen，Guangdong

Online inquiry

Previous Next

Detailed content Specification parameter Product packaging

MODEL	SW-48100	SW-48200	SW-51100	SW-51200
Electrical Characteristics
Rate voltage(Vdc)	48		51.2
Cell combination	15S1P	15S2P	16S1P	16S2P
Rate capacity(AH)	100	200	100	200
Energy storage(KWH)	4.8	9.6	5.12	10.24
Cycle life	6000 cycles @80% DOD, 0.5C
Charge/Discharge Standard
Charge voltage(V)	52.5		56
Max. charge current(A)	100 (Optional 150/200A for 200AH pack)
Max. discharge current(A)	100 (Optional 150/200A for 200AH pack)
Discharge cut-o voltage(VDC)	40.5		43.2
Charge cut-o voltage(VDC)	54.75		58.4
Enviornment
Charge temperature	0°C to 55°C@60±25% Relative Humidity
Discharge temperature	-20°C to 55°C@60±25% Relative Humidity
Storage temperature	-20°C to 55°C@60±25% Relative Humidity
Mechanical
IP class	IP20 (IP65 Option available for 100AH model)
Material system	LiFePO4
Case material	Metal
Case type	Wall Mount
Pack dimension LWH(mm)	580390185	690485226	580390185	690485226
Package dimension LWH(mm)	660450240	850570285	660450240	850570285
Net weight(kg)	42	85	44	88
Gross weight(kg)	47	95	49	98
Communication
Protocol(Optional)	Canbus/RS485/RS232
Monitoring	Bluetooth/WLAN Optional
Certificates
Pack	UN38.3, MSDS	CE/IEC/UL1973	CE/UN38.3/MSDS	UN38.3, MSDS
Cell	UN38.3, MSDS, IEC62619, CE, UL1973
