51.2V Rack-Mounted Lithium Battery-Jiangsu Sloer Group Co., ltd

51.2V Rack-Mounted Lithium Battery Id：SR-51100/51200/51300

Online inquiry

Previous Next

Detailed content Specification parameter Product packaging

MODEL	SR-48100	SR-48200	SR-51100	SR-51200	SR-51280
Electrical Characteristics
Rate voltage(Vdc)	48		51.2
Cell combination	15S1P	15S2P	16S1P	16S2P	16S1P
Rate capacity(AH)	100	200	100	200	280
Energy storage(KWH)	4.8	9.6	5.12	10.24	14.33
Cycle life	6000 cycles @80% DOD, 0.5C
Charge/Discharge Standard
Charge voltage(V)	52.5		56
Max. charge current(A)	100 (Optional 150/200A for 200AH pack)
Max. discharge current(A)	100 (Optional 150/200A for 200AH pack)
Discharge cut-off voltage(VDC)	40.5		43.2
Charge cut-off voltage(VDC)	54.75		58.4
Enviornment
Charge temperature	0°C to 55°C@60±25% Relative Humidity
Discharge temperature	-20°C to 55°C@60±25% Relative Humidity
Storage temperature	-20°C to 55°C@60±25% Relative Humidity
Mechanical
IP class	IP20
Material system	LiFePO4
Case material	Metal
Case type	Rack Mount
Pack dimension LWH(mm)	480483133 (3U)	680442178 (4U)	480483133 (3U)	680483178 (4U)	780430230 (5U)
Package dimension LWH(mm)	580530210	850570285	580530210	850570285	890720430
Net weight(kg)	42	84	44	88	116
Gross weight(kg)	47	93	49	97	137
Communication
Protocol(Optional)	Canbus/RS485/RS232
Certificates
Pack	UN38.3, MSDS	UN38.3, MSDS	IEC62619,CE,UL1973	UN38.3, MSDS,CE	UN38.3, MSDS
Cell	UN38.3, MSDS, IEC62619, CE, UL1973
